No Capacitor Smart Life/Tuya 2/3 Way Control compatible AlexaGoogle

ZigBee Wall Touch Smart Light Switch: Seamless Integration and Enhanced Control

This document provides a comprehensive overview of the ZigBee Wall Touch Smart Light Switch, highlighting its innovative features, installation procedures, and functionalities. Designed for modern smart homes, this switch integrates seamlessly with existing electrical systems while offering advanced control options.

Product Overview

The ZigBee Wall Touch Smart Light Switch is a versatile smart home solution for controlling lighting. It operates on the ZigBee protocol, and while compatible with various hubs, superior performance and broader compatibility are achieved with a Tuya ZigBee hub. Employing a touch-sensitive interface, this switch offers a blend of convenience and aesthetics. Crucially, it accommodates both neutral and non-neutral wiring configurations, addressing a wide range of home electrical setups. The switch features a robust construction with a scratch-resistant glass panel and offers the ease of voice control through integration with Alexa and Google Home. Furthermore, it includes essential features like 2-way/3-way control, timer capabilities, and family sharing options, enabling versatile and intuitive functionality within any household.

Key Features for Effortless Control

The ZigBee Wall Touch Smart Light Switch surpasses traditional light switches by incorporating a suite of smart features. Its design prioritizes user experience, resulting in a sophisticated solution for modern living.

Neutral Wire/No Neutral Wire Option: This switch caters to various electrical setups by providing options for both neutral and non-neutral wiring configurations. This ensures compatibility with a broader range of home electrical systems, lessening the need for adjustments.

No Capacitor Needed: A significant improvement is the elimination of the capacitor, a component often associated with noise during operation. By dispensing with the capacitor, the switch provides a smoother and quieter experience, enhancing user comfort, particularly in bedrooms.

2/3-Way Multi-Control Association: The switch provides sophisticated support for 2-way and 3-way lighting control. Through a multi-control association feature in the app, users can link the switch to other compatible smart switches, enabling seamless control of lights via multiple points within the dwelling. While multiple gangs on one switch aren't supported for multi-control, the single gang association capability remains unmatched. The system remembers the last switching state when the power is abruptly cut, and users can control the presence and intensity of the backlight through app-based settings.

Versatile Control Methods: The switch transcends traditional control methods, providing a comprehensive system for adjusting illumination. Users can manage the switch through the associated app, using touch sensing, and giving vocal commands via voice assistant platforms such as Alexa and Google Home.

Voice Control Integration: Integration with popular voice assistants like Alexa and Google Home extends the convenience and accessibility of the switch. This seamless integration allows for hands-free operation, enhancing the responsiveness of the smart home setup.

Advanced Timing and Scheduling: The app-based interface enables users to set timers for lights, facilitating pre-programmed illumination. Programmable timers include options for 1/5/30 minutes, 1 hour, and other pre-defined intervals.

Family Sharing Capabilities: The switch facilitates shared control amongst family members. Users can share devices and establish group controls to streamline management and coordination throughout the household. This shared control feature assists in simplifying household management for multiple users.

Installation and Setup (with Neutral Wire)

Step-by-Step Guide for Neutral Wire Configuration:

1. Wiring Step 1: Wire switch 1 to N+L+L1.
2. Wiring Step 2: Wire switch 2 to N+L, needing no additional connection to the light fixture.
3. Configuration Setup 1: Complete the switch 1 configuration within the associated app.
4. Configuration Setup 2: Associate switch 1 to switch 2 within the app to activate the 2-way function.

Utilizing this structured two-step association, the 2-way function activates. For additional 3-way or multi-way control, repeat the association process for each switch.

Installation and Setup (without Neutral Wire)

If your electrical configuration lacks a neutral wire, simply bypass the N position in the wiring process. All other steps remain consistent.

Maintenance and Troubleshooting

Regular monitoring of the switch's operation and firmware updates are vital to ensure optimal performance. Consult the user manual or contact the manufacturer for detailed instructions and guidance.

Technical Specifications

• Working Voltage: AC100-250V, 50/60Hz
• Current Type: Total 10A
• Inductive Load (LED/CFL): 3-120W
• Resistive Load (Incandescent): 3-300W (110V) / 3-600W (220V)
• Wireless Type: Wi-Fi 2.4GHz
• Power Consumption: ≤0.5W
• Working Temperature: 0°C ~ 40°C
• Supported Systems: Android/iOS

This information offers a comprehensive overview of the ZigBee Wall Touch Smart Light Switch's capabilities and functionalities within a smart home setting. The user-friendly interface and adaptable installation methods make it a valuable addition to any household that seeks advanced control and convenience for their lighting systems. Remember to always consult the product manual for detailed specifications and safety precautions.

New Arrival Upgraded with More Personalized Points:

Provide much more convenience and updates for your smart lifestyle with the price unchanged as before.

Update 1:  No Capacitor Required
Others:Capacitor required for normal use whose noise from electriccurrent is inevitable.
Ours:No more worry about being affected by the noise from the capacitor when sleep, with no capacitor required as complex  installations anymore for normal use.

Update2:  One Switch For Two Wirings Optional

Update3:  A New ldea For 3 Way Control
Multi-control association of the switch to another ZigBee smart switch in the App for achieving Way feature(two switches control one light).
Note:  There is no need to wire the new added switch to the light, only  L and N are required for wiring. (for neutral wire version)

Update4:  New ON/ OFF Relay Status in App
More personalized settings as ON/ OFF/ Remember last status when power off.

Update5:  Backlight Mode

Backlight switch with ON / OFF optional will not affect your sleep.

New ZigBee Smart Switch
No capacitor required / one switch for two wirings optional

Note: If there is no neutral wire in your house, just ignore the N position for wiring, and if there is one, just wire it for normal use.

ZigBee Smart Switch

This WiFi indicator is for signal transmission, not for it is a WiFi version featured, it is a ZigBee smart switch with ZigBee protocol.

Durability/Toughened Glass/Damp Proof

Two placement methods
Easily choose the installation method with horizontal or vertical to cater to your desired style.

Smart Life Tuya Remote Control

Remotely control  your switch wherever you are.

Hands-free Voice Control
Free hands via easy voice control with Alexa and Google Home.
Note:  Hub is not included in the package.

Timer Function
Timing setting and countdown options.

Family Sharing
Add device to your Smart Life App to get multiple control ways for controlling with your family together.

Multiple people control one  /  One person controls more than one

You can create group in the APP to manage all the lights in your house and share the device to your family members.

How to achieve 3 way/multi-control

Step  1
1. Wire switch 1 to N+L+L1
2. Wire switch 2 to N+ L, no light needed
Step 2
1 Complete the confguration of switch 1 to APP  2. Achieve 2 way by associating switch 1 to switch 2
Note: For neutral wire required  version only

Step 3
Now you can manual and app control one same  light With switch 1 and Switch 2 at the same time
Step 4
Multi-control associate to more switches by repeating  steps above to acheive 3 or more switches to control  One Same light
Note:  there is no neutral wire in your house, just ignore  the N position for wiring, and if there is one, just  wire it for normal use.
Note: No capacitor required  for easy installations.

Main Specifications:

Working voltage:AC100-250V,50/60Hz

Current type:Total 10A

Inductive load(LED/CFL):3-120W

Resistive load(Incandescent):3-300W for 110V;3-600W for 220V

Wireless type:Wi-Fi 2.4GHz

Power consumption:≤0.5W

Working temperature:0℃~40℃

Support system:Android\iOS
